Sunsynk 50kW, HV 3 Phase Hybrid Inverter

• Rated AC / UPS Output: 50,000 W (50kW) • Max AC Power: 55,000 W (up to 5 minutes) • Surge AC Power: 75,000 W (1 second) • Max DC Solar Input: 65,000 W (supports up to 30% DC oversizing) • MPPT Trackers / Strings: 4 MPPT trackers and 8 strings • MPPT Voltage Range: 150V – 850V (Startup voltage: 180V) • Max DC Input Voltage: 1,000V (Max input current: 144A) • Battery Voltage Range: 160V – 800V (High-voltage lithium-ion compatibility) • Max Efficiency: 97.6% • Enclosure / Protection: IP65 weatherproof rating, integrated Type II DC/AC SPD, and anti-islanding protection • Dimensions & Weight: 527 x 894 x 294 mm; weighs approximately 75–80 kg
